302
SWITCHES
MULTIPLE-STATION SWITCHES PHONE: 773 792-2700
* Please visit the product pages on our website for the most up-to-date product information
MULTIPLE-STATION SWITCHES (continued)
SERIES 90000, 920000
TINI DW MULTI-SWITCH
SERIES 35000
LITTEL ? MULTI-SWITCH
SERIES 37000, 38000
LITTEL ? MULTI-SWITCH
CHOOSING THE RIGHT MULTIPLE-STATION SWITCH
Switching
Switch
Mechanical
Stations
Per Station
Contact
Series
35000
Functions 1
ILO, N, A, PL/PR
(Maximum)
18
(Maximum)
6PDT
Rating 2
2A AC, 200W
Lighting
No
Accessories 3
C, G, M, P, S, PC/WW
36000
6PDT
No
37000
ILO, N, A, PL/PR
18
4PDT
2A AC, 200W
Yes
C, G, M, P, S,
38000
3PDT
Yes
PC/WW, LWO
65000
66000
ILO, N, A, PL/PR
ILO, N, A, PL/PR
18
18
4PDT
4PDT
3A AC, 0.5A DC
3A AC, 0.5A DC
No
No
C, G, M, S, PC/WW
C, G, M, S, PC/WW
67000
Yes
90000
92000
IBS
ILO, N, A
I, N
12 - ILO, A
18 - N, PL/PR
12
8PDT
2PDT
0.5A 28V AC or DC
.125A, 125 VAC
or 28 VDC
No
No
M
P, M
1. I = interlock, ILO = interlock with lockout, N = non-lock (momentary), A = all-lock (special order), PL/PR = push-lock/push-release.
2. Non-inductive load.
3. C = optional switch contact, G = ganged assemblies, M = special/mixed functions, P = optional pushbuttons, S = solenoid release, PC/WW = PC and
wire-wrapping terminals, LWO = lighting wiring options.
ORDERING
Order switches by part number in this section.
For any optional or special order feature, contact Switchcraft.
DIMENSIONS ARE FOR REFERENCE ONLY
www.switchcraft.com
Inch
(mm)
? Registered trademark of Switchcraft, Inc.
Note: Contact your Switchcraft Representative for price and delivery
